Trussing

Truss plays an important role in many events. It is most commonly used to build structures on which equipment such as lighting, audio, video, or decor can be hung.

By using different lengths and corners, you can create the most remarkable creations. All the components can be seen as a kind of LEGO blocks that fit together. These structures can be self-supporting on legs or suspended using hoists.

Prolyte H30V

The H30V series is a truss standard produced by Prolyte. This series is known for its versatile use, strong construction, and long lifespan. These trusses are perfect for use on stages, at trade shows, at conferences, outdoor banners, and much more!

The H30V series from Prolyte is the Heavy-duty variant. The wall thickness of this truss is 3mm. Most competing brands, including Prolyte's own X30V series, have a wall thickness of only 2mm. This difference may seem small, but it makes the H-series much sturdier. This allows for larger spans and higher load capacities.

H30V-L029

Now let's focus on the specific piece. The H30V-L029 by Prolyte is a 29cm length truss. It is commonly used to connect corner sections to a circular length. H30V truss has a standard length of 29cm. To facilitate the construction of structures, the corner sections are 50x50cm, protruding 21cm from the standard 29cm length. However, when you want to connect more than one corner, such as in a T-junction C017 or C020, you will have the protrusion on both sides. To remain compatible with the other corner sections, an additional 21cm is added on the opposite side. Therefore, the total width of such a corner piece becomes 71cm.

To bring this "odd" measurement back to a meter, this 29cm section is often used. This ensures that the corners of your project fit exactly where they need to be!

General

Brand Prolyte
Type H30V-L029
Coupler system CCS6
Weight 2,9 kg


Dimentions

Width 29cm
Height 29cm
Length 29cm


Accessories

CCS6 Coupler 4 pieces
CCS6 Screwpin 4 pieces


Downloads

Prolyte H30V Loadingtable Loading Table H30V - pdf
Prolyte H30V Datasheet Product Data Sheet H30V - pdf


Trussing

Prolyte H30V-L029

Prolyte H30V is an aluminium based trussing system that is used in the entertainment industry. It’s main purpose is to hang or support other equipment.

starting from

€5,00
